Pressure Gauge for Mud, Water, Oil, Gas or Liquid

Pressure Gauge for Mud, Water, Oil, Gas or Liquid

VigorPetro Pressure Gauges Overview

VigorPetro manufactures Models 6/TypeF, 7/TypeD, & 8 pressure gauges for standard, salt water, and sour gas service. Models 6 & 7 have many common features. In addition to the common features, the Model 6 has a pressure range up to 20,000 psi and the Model 7 has a range up to 6,000 psi. For dual dial face requirements with pressures to 20,000 psi, see the Model 8 information below.

Common Features & Benefits

★ Gauges are manufactured in VigorPetro's own factory ensuring the highest quality

★ The built-in dampening mechanism minimizes wear and mechanical shock providing

longer gauge life

★ Heavy duty seals restrict line fluid from entering gauge mechanism

★ The gauge mechanism is surronded by a special oil providing resistance to extreme

temperatures, as well as, vibration and shock

★ Utilization of safety plugs prevent gauge explosion due to over pressurization

★ 100% interchangeable with Oteco & Cameron Gauges.

Model 6/Type ‘F’-Union   Model 8    Model 7 Male/Type ‘D’   Model 6/Type ‘F’-Flange

Specifications:

Models* 6/Type F, 7/Type D, Model 8

Pressures* Up to 20,000 psi

Dial Face Units* PSI, kPa, Bar, kg/cm sqr.

Service Types* Standard, Sour Gas, Oil, Waterflood

Temp. Rating* -50° F / 180° F

Connections* Union, Threaded and Flanged
